Specifications
Chase Dimensions 270/450mm
2 Color Printing Dimensions 260/220mm/2Faces
3 Color Printing Dimensions 260/145mm/3Faces
4 Color Printing Dimensions 260/108mm/4Faces
Maximum Paper Width 270mm
Cutting Dimensions 270/300mm
Maximum Printing Speed 35~150Rpm
Electric Power 3Phases. 220V/380V
Main Motor 2.2Kw/8EA
Net Weight Approx. 3,800 Kg
Machine Size (L)2,695(W)1,200(H)1,850
Characteristic
1.High quality servomotor driven automatic label printing machine
2.1 printing + 1 Die-cutting station
3.Driven accurate and easy control by order
4.Servomotor driven accurate and easy 2nd pass system
5.Equipped waste paper tension control system
6.Twisting turn adjustment is available for Die-Cut upper chase in addition to Left/Right and Forward/Backward adjustment
7.Equipped powerful operation system
8.Exclusive powerful system performing accurate and even printing and die-cutting
9.Optional - UV dryer / Hot foil stamping / Pungching
